2.0mm Single Mode Duplex Armored Fiber Optic Patch Cord / Jumper

Name: 20mm Single Mode Duplex Armored Fiber Optic Patch Cord Jumper
Brand: DYS/OEM
Price: 1 USD

Buy cheap 2.0mm Single Mode Duplex Armored Fiber Optic Patch Cord / Jumper product

Place of Origin : shenzhen

Brand Name : DYS/OEM

Certification : IS09001-2015.ROHS

Model Number : FC/UPC - Mu /UPC

MOQ : Negotiable

Price : Negotiable

Packaging Details : Individual box or according to customer's request

Delivery Time : IN 3 Days

Payment Terms : L/C,T/T

Supply Ability : 2000/WEEKS

Contact Now

2.0mm Single Mode Duplex Armored Fiber Optic Patch Cord / Jumper

Quick Details

Brand Name: DYS

Model Number: Environmental IP67

Mode: Singlemode

Insertion Loss≤0.2 dB

Salt Spray≤0.1dB

Repeatability:≤0.1dB (1000 times)

Apex Offset:0μm ~ 50μm

Quick Detail:

Model Number: FC- Mu

Polishing: UPC

Mode: Singlemode

Core: Simplex

Jacket Color: Blue

Material: LSZH

Cable OD: 2.0mm

Cable Lengh: 20m

Specification

Mode	SM		MM
Polish	UPC	APC	PC
Insertion Loss	≤0.2dB	≤0.3dB	≤0.2dB
Return Loss	≥55dB	≥65dB	≥35dB
Interchangeability	≤0.2dB
Salt Spray	≤0.1dB
Repeatability	≤0.1dB (1000 times)
Vibration	≤0.2dB (550Hz 1.5mm)
Temperature	≤0.2dB (-40+85 sustain 100 hours)
Humidity	≤0.2dB (+25+65 93 R.H.100 hours)
Apex Offset	0μm ~ 50μm
Radius of Curvature	7mm ~ 25mm

Features:

- Low insertion loss value. High return loss value .

- Stable capability , high reliablity and precise connector.

- Excellent mechanical capability .

- Accord with GR-326 experiment and ROHS.

Applications:

Machine room

FTTH

Area network

Test equipment

National defence

FO sensor

Light communication system

Common antenna TV system

2.0mm Single Mode Duplex Armored Fiber Optic Patch Cord / Jumper

Competitive Advantage

DYS strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, productsexported to Europe and the United States and Southeast Asian countries.

Product Tags:

fiber optic jumper

multimode fiber optic cable

2.0mm Single Mode Duplex Armored Fiber Optic Patch Cord / Jumper Images
